Product Details

Description:

The needle roller bearing without inner ring is suitable for the parts of which the radial size is limited.Because of no inner ring, the surface of shaft journal fitted with it is acted directly as rolling surface. It is requested that the surface hardness be no less than HRC60, surface roughness, no more than 0.63um. This kind of bearing does not limit the axial shift of shaft and housing and has high limiting rotational speed.

The inner ring has no shoulder in this bearing. For this purpose, the inner ring, outer ring complete set of needles and cage can be mounted respectively. This bearing does not limit the axial shift of shaft and outer housing. Since the cage separates the needles so as to reduce friction. It can be used for the parts with high rotational speed.

Shaft	Model	Boundary Dimensions						Basic Load Rating		Limiting Speed
		d	F	D		B	rS	Dynamic	Static	Grease

								C	Co
mm		mm			Min.			N		rpm
5	+NKI 5/12 TN	5	8	15		12	0.3	3950	4100	32000
5	+NKI 5/16 TN	5	8	15		16	0.3	5100	5800	32000
6	+NKI 6/12 TN	6	9	16		12	0.3	4500	5000	31000
	+NKI 6/16 TN	6	9	16		16	0.3	5900	7100	31000
	+NKIS 6 TN	6	10	19		13	0.3	5800	6000	29000
7	+NKI 7/12 TN	7	10	17		12	0.3	4750	5500	29000
	+NKI 7/16 TN	7	10	17		16	0.3	6200	7800	29000
	+NKIS 7 TN	7	12	22		16	0.6	9600	10400	26000
8	NKIS 8	8	14	25		16	0.6	14400	13800	24000
9	NKI 9/12	9	12	19		12	0.3	6400	7100	27000
	NKI 9/16	9	12	19		16	0.3	9000	11000	27000
	NKIS 9	9	15	26		16	0.6	14400	14000	23000
10	NKI 10/16	10	14	22		16	0.3	10100	11500	25000
	NKI 10/20	10	14	22		20	0.3	12800	15600	25000
	INKIS 10	10	16	28		16	0.6	15700	15800	22000
	NA 4900	10	14	22		13	0.3	8500	9200	25000
12	NKI 12/16	12	16	24		16	0.3	11300	13900	23000
	NKI 12/20	12	16	24		20	0.3	14400	18800	23000
	INKIS 12	12	18	30		16	0.6	16800	17700	21000
	NA 4901	12	16	24		13	0.3	9400	10900	23000
	NA 6901	12	16	24		22	0.3	16000	21600	23000
15	NKI 15/16	15	19	27		16	0.3	13000	17400	22000
	NKI 15/20	15	19	27		20	0.3	16500	23600	22000
	INKIS 15	15	22	35		20	0.6	24500	28000	18000
	NA 4902	15	20	28		13	0.3	10600	13600	21000
	NA 6902	15	20	28		23	0.3	17300	25500	21000
17	NKI 17/16	17	21	29		16	0.3	13500	18700	21000
	NKI 17/20	17	21	29		20	0.3	17100	25500	21000
	NKIS 17	17	24	37		20	0.6	26000	31000	17000
	NA 4903	17	22	30		13	0.3	11000	14600	20000
	NA 6903	17	22	30		23	0.3	18600	29000	20000
20	NKI 20/16	20	24	32		16	0.3	15000	22300	18000
	NKI 20/20	20	24	32		20	0.3	19000	30500	18000
	NKIS 20	20	28	42		20	0.6	28500	36500	15000
	NA 4904	20	25	37		17	0.3	21000	25500	17000
	NA 6904	20	25	37		30	0.3	36000	51000	17000
22	NKI 22/16	22	26	34		16	0.3	15300	23600	17000
	NKI 22/20	22	26	34		20	0.3	19400	32000	17000
	NA 49/22	22	28	39		17	0.3	22800	29500	15000
	NA 69/22	22	28	39		30	0.3	37500	55000	15000
25	NKI 25/20	25	29	38		20	0.3	21900	34000	15000
	NKI 25/30	25	29	38		30	0.3	32500	57000	15000
	NKIS 25	25	32	47		22	0.6	33500	43500	13000
	NA 4905	25	30	42		17	0.3	23600	31500	14000
	NA 6905	25	30	42		30	0.3	29000	59000	14000
28	NKI 28/20	28	32	42		20	0.3	23100	37500	14000
	NKI 28/30	28	32	42		30	0.3	34500	63000	14000
	NA 49/28	28	32	45		17	0.3	24400	33500	14000
	NA 69/28	28	32	45		30	0.3	40500	63000	14000
30	NKI 30/20	30	35	45		20	0.3	24300	41500	13000
	NKI 30/30	30	35	45		30	0.3	36500	69000	13000
	NKIS 30	30	37	52		22	0.6	36500	50000	12000
	NA 4906	30	35	47		17	0.3	25000	35500	13000
	NA 6906	30	35	47		30	0.3	43500	71000	13000
32	NKI 32/20	32	37	47		20	0.3	24900	43500	12000
	NKI 32/30	32	37	47		30	0.3	37000	73000	12000
	NA 49/32	32	40	52		20	0.6	30500	47500	11000
	NA 69/32	32	40	52		36	0.6	47000	82000	11000
35	NKI 35/20	35	40	50		20	0.3	26000	47000	11000
	NKI 35/30	35	40	50		30	0.3	39000	79000	11000
	NKIS 35	35	43	58		22	0.6	39000	57000	10000
	NA 4907	35	42	55		20	0.6	31500	50000	11000
	NA 6907	35	42	55		36	0.6	48000	86000	11000
38	NKI 38/20	38	43	53		20	0.3	27000	51000	11000
38	NKI 38/30	38	43	53		30	0.3	40500	85000	11000
40	NKI 40/20	40	45	55		20	0.3	27500	53000	10000
	NKI 40/30	40	45	55		30	0.3	41000	88000	10000
	NKIS 40	40	50	65		22	1	42500	67000	9000
	NA 4908	40	48	62		22	0.6	43000	67000	9000
	NA 6908	40	48	62		40	0.3	66000	116000	9000
42	NKI 42/20	42	47	57		20	0.3	28500	56000	10000
42	NKI 42/30	42	47	57		30	0.3	43000	94000	10000
45	NKI 45/25	45	50	62		25	0.6	38000	74000	9000
	NKI 45/35	45	50	62		35	0.6	50000	106000	9000
	NKIS 45	45	55	72		22	1	45000	74000	8000
	NA 4910	45	52	68		22	0.6	45000	73000	8500
	NA 6910	45	52	68		40	0.6	69000	127000	8500
50	NKI 50/25	50	55	68		25	0.6	40000	82000	8500
	NKI 50/35	50	55	68		35	0.6	53000	118000	8500
	NKIS 50	50	60	80		28	1.1	63000	98000	7500
	NA 4910	50	58	72		22	0.6	47000	80000	8000
	NA 6910	50	58	72		40	0.6	73000	139000	8000
55	NKI 55/25	55	60	72		25	0.6	42000	90000	7500
	NKI 55/35	55	60	72		35	0.6	56000	130000	7500
	NKIS 55	55	65	85		28	1.1	67000	108000	7000
	NA 4911	55	63	80		25	1	58000	100000	7000
	NA 6911	55	63	80		45	1	90000	176000	7000
60	NKI 60/25	60	68	82		25	0.6	43500	89000	7000
	NKI 60/35	60	68	82		35	0.6	62000	139000	7000
	NKIS 60	60	70	90		28	1.1	68000	113000	6500
	NA 4912	60	68	85		25	1	60000	108000	6500
	NA 6912	60	68	85		45	1	94000	191000	6500
65	NKI 65/25	65	73	90		25	1	53000	100000	6500
	NKI 65/35	65	73	90		35	1	75000	156000	6500
	NKIS 65	65	75	95		28	1.1	71000	123000	6000
	NA 4913	65	72	90		25	1	61000	112000	6500
	NA 6913	65	72	90		45	1	95000	198000	6500
70	NKI 70/25	70	80	95		25	1	56000	119000	6000
	NKI 70/35	70	80	95		35	1	78000	184000	6000
	NKIS 70	70	80	100		28	1.1	75000	133000	5500
	NA 4914	70	80	100		30	1	84000	156000	5500
	NA 6914	70	80	100		54	1	128000	265000	5500
75	NKI 75/25	75	85	105		25	1	69000	123000	5500
	NKI 75/35	75	85	105		35	1	98000	193000	5500
	NA 4915	75	85	105		30	1	86000	162000	5500
	NA 6915	75	85	105		54	1	130000	275000	5500
80	NKI 80/25	80	90	110		25	1	72000	132000	5000
	NKI 80/35	80	90	110		35	1	103000	208000	5000
	NA 4916	80	90	110		30	1	89000	174000	5000
	NA 6916	80	90	110		54	1	135000	300000	5000
85	NKI 85/26	85	95	115		26	1	73000	137000	4800
	NKI 85/36	85	95	115		36	1	107000	223000	4800
	NA 4917	85	100	120		35	1.1	111000	237000	4600
	NA 6917	85	100	120		63	1.1	166000	400000	4600
90	NKI 90/26	90	100	120		26	1	76000	146000	4600
	NKI 90/36	90	100	120		36	1	111000	237000	4600
	NA 4918	90	105	125		35	1.1	114000	250000	4400
	NA6918	90	105	125		63	1.1	172000	425000	4400
95	NKI 95/26	95	105	125		26	1	78000	155000	4400
	NKI 95/36	95	105	125		36	1	114000	250000	4400
	NA 4919	95	110	130		35	1.1	116000	260000	4200
	NA 6919	95	110	130		63	1.1	174000	440000	4200
100	NKI 100/30	100	110	130		30	1.1	98000	210000	4200
	NKI 100/40	100	110	130		40	1.1	127000	290000	4200
	NKIS 100	100	115	135		32	1.1	91000	204000	4000
	NA 4920*)	100	115	140		40	1.1	128000	270000	4000
110	NKI 110/40	110	120	140		40	1.1	113000	275000	3900
	NA 4922*)	110	125	150		40	1.1	132000	290000	3700
	NA 4822*)	110	120	140		30	1	94000	216000	3900
120	NA 4924*)	120	135	165		45	1.1	181000	390000	3400
120	NA 4824*)	120	130	150		30	1	99000	239000	3600
75	NA 4926*)	130	150	180		50	1.5	203000	470000	3100
75	NA 4826*)	130	145	165		35	1.1	118000	310000	3200
140	NKI 140/32	140	155	180		32	1.5	114000	260000	3000
	NA 4928*)	140	160	190		50	1.5	209000	500000	2900
	NA 4828*)	140	155	175		35	1.1	120000	325000	3000
150	NA 4830*)	150	165	190		40	1.1	152000	400000	2800
160	NA 4832*)	160	175	200		40	1.1	160000	435000	2700
170	NA 4834	170	185	215		45	1.1	185000	510000	2500
180	NA 4836*)	180	195	225		45	1.1	194000	550000	2400
190	NA 4838	190	210	240		50	1.5	227000	690000	2300
200	NA 4940*)	200	220	250		50	1.5	230000	720000	2200
220	NA 4844*)	220	240	270		50	1.5	243000	790000	2000
240	NA 4848*)	240	265	300		60	2	355000	1080000	1800
260	NA 4852*)	260	285	320		60	2	370000	1160000	1700
280	NA 4856*)	280	305	350		69	2	450000	1300000	1500
300	NA 4860*)	300	330	380		80	2.1	620000	1770000	1400
320	NA 4864	320	350	400		80	2.1	630000	1850000	1300
340	NA 4868	340	370	420		80	2.1	640000	1940000	1300
360	NA 4872	360	390	440		80	2.1	660000	2020000	1200
380	NA 4876	380	415	480		100	2.1	100000	2900000	1100
Shaft	Model	Boundary Dimensions						Basic Load Rating		Limiting Speed
		d	F	D		B	rS	Dynamic	Static	Grease
		d	F	D		B	rS	C	Co	Grease
mm		mm			Min.			N		rpm
38	NKI 38/20	38	43	53		20	0.3	27000	51000	11000
38	NKI 38/30	38	43	53		30	0.3	40500	85000	11000
40	NKI 40/20	40	45	55		20	0.3	27500	53000	10000
	NKI 40/30	40	45	55		30	0.3	41000	88000	10000
	NKIS 40	40	50	65		22	1	42500	67000	9000
	NA 4908	40	48	62		22	0.6	43000	67000	9000
	NA 6908	40	48	62		40	0.3	66000	116000	9000
42	NKI 42/20	42	47	57		20	0.3	28500	56000	10000
42	NKI 42/30	42	47	57		30	0.3	43000	94000	10000
45	NKI 45/25	45	50	62		25	0.6	38000	74000	9000
	NKI 45/35	45	50	62		35	0.6	50000	106000	9000
	NKIS 45	45	55	72		22	1	45000	74000	8000
	NA 4910	45	52	68		22	0.6	45000	73000	8500
	NA 6910	45	52	68		40	0.6	69000	127000	8500
50	NKI 50/25	50	55	68		25	0.6	40000	82000	8500
	NKI 50/35	50	55	68		35	0.6	53000	118000	8500
	NKIS 50	50	60	80		28	1.1	63000	98000	7500
	NA 4910	50	58	72		22	0.6	47000	80000	8000
	NA 6910	50	58	72		40	0.6	73000	139000	8000
55	NKI 55/25	55	60	72		25	0.6	42000	90000	7500
	NKI 55/35	55	60	72		35	0.6	56000	130000	7500
	NKIS 55	55	65	85		28	1.1	67000	108000	7000
	NA 4911	55	63	80		25	1	58000	100000	7000
	NA 6911	55	63	80		45	1	90000	176000	7000
60	NKI 60/25	60	68	82		25	0.6	43500	89000	7000
	NKI 60/35	60	68	82		35	0.6	62000	139000	7000
	NKIS 60	60	70	90		28	1.1	68000	113000	6500
	NA 4912	60	68	85		25	1	60000	108000	6500
	NA 6912	60	68	85		45	1	94000	191000	6500
65	NKI 65/25	65	73	90		25	1	53000	100000	6500
	NKI 65/35	65	73	90		35	1	75000	156000	6500
	NKIS 65	65	75	95		28	1.1	71000	123000	6000
	NA 4913	65	72	90		25	1	61000	112000	6500
	NA 6913	65	72	90		45	1	95000	198000	6500
70	NKI 70/25	70	80	95		25	1	56000	119000	6000
	NKI 70/35	70	80	95		35	1	78000	184000	6000
	NKIS 70	70	80	100		28	1.1	75000	133000	5500
	NA 4914	70	80	100		30	1	84000	156000	5500
	NA 6914	70	80	100		54	1	128000	265000	5500
75	NKI 75/25	75	85	105		25	1	69000	123000	5500
	NKI 75/35	75	85	105		35	1	98000	193000	5500
	NA 4915	75	85	105		30	1	86000	162000	5500
	NA 6915	75	85	105		54	1	130000	275000	5500
80	NKI 80/25	80	90	110		25	1	72000	132000	5000
	NKI 80/35	80	90	110		35	1	103000	208000	5000
	NA 4916	80	90	110		30	1	89000	174000	5000
	NA 6916	80	90	110		54	1	135000	300000	5000
85	NKI 85/26	85	95	115		26	1	73000	137000	4800
	NKI 85/36	85	95	115		36	1	107000	223000	4800
	NA 4917	85	100	120		35	1.1	111000	237000	4600
	NA 6917	85	100	120		63	1.1	166000	400000	4600
90	NKI 90/26	90	100	120		26	1	76000	146000	4600
	NKI 90/36	90	100	120		36	1	111000	237000	4600
	NA 4918	90	105	125		35	1.1	114000	250000	4400
	NA6918	90	105	125		63	1.1	172000	425000	4400
95	NKI 95/26	95	105	125		26	1	78000	155000	4400
	NKI 95/36	95	105	125		36	1	114000	250000	4400
	NA 4919	95	110	130		35	1.1	116000	260000	4200
	NA 6919	95	110	130		63	1.1	174000	440000	4200
轴径	轴承型号	外型尺寸						基本额定负荷		极限转速
		d	F	D		B	rS	动	静	油润滑
		d	F	D		B	rS	C	Co	油润滑
mm		mm			Min.			N		rpm
100	NKI 100/30	100	110	130		30	1.1	98000	210000	4200
	NKI 100/40	100	110	130		40	1.1	127000	290000	4200
	NKIS 100	100	115	135		32	1.1	91000	204000	4000
	NA 4920*)	100	115	140		40	1.1	128000	270000	4000
110	NKI 110/40	110	120	140		40	1.1	113000	275000	3900
	NA 4922*)	110	125	150		40	1.1	132000	290000	3700
	NA 4822*)	110	120	140		30	1	94000	216000	3900
120	NA 4924*)	120	135	165		45	1.1	181000	390000	3400
120	NA 4824*)	120	130	150		30	1	99000	239000	3600
75	NA 4926*)	130	150	180		50	1.5	203000	470000	3100
75	NA 4826*)	130	145	165		35	1.1	118000	310000	3200
140	NKI 140/32	140	155	180		32	1.5	114000	260000	3000
	NA 4928*)	140	160	190		50	1.5	209000	500000	2900
	NA 4828*)	140	155	175		35	1.1	120000	325000	3000
150	NA 4830*)	150	165	190		40	1.1	152000	400000	2800
160	NA 4832*)	160	175	200		40	1.1	160000	435000	2700
170	NA? 4834	170	185	215		45	1.1	185000	510000	2500
180	NA? 4836*)	180	195	225		45	1.1	194000	550000	2400
190	NA? 4838	190	210	240		50	1.5	227000	690000	2300
200	NA 4940*)	200	220	250		50	1.5	230000	720000	2200
220	NA? 4844*)	220	240	270		50	1.5	243000	790000	2000
240	NA? 4848*)	240	265	300		60	2	355000	1080000	1800
260	NA? 4852*)	260	285	320		60	2	370000	1160000	1700
280	NA 4856*)	280	305	350		69	2	450000	1300000	1500
300	NA? 4860*)	300	330	380		80	2.1	620000	1770000	1400
320	NA? 4864	320	350	400		80	2.1	630000	1850000	1300
340	NA? 4868	340	370	420		80	2.1	640000	1940000	1300
360	NA? 4872	360	390	440		80	2.1	660000	2020000	1200
380	NA? 4876	380	415	480		100	2.1	100000	2900000	1100
